Description:

Specifications:

• Engine
• Engine Brand: Kawasaki
• Model: FX801V V-Twin
• Air Filter: Heavy-duty
• Drive System
• System Type: Two Exmark-exclusive Parker unitized pump and wheel motor systems
• Features:
• No hoses
• Integrated cooling fans
• 1.7-quart integrated reservoir
• Spin-on filter
• Heavy-duty components
• 12cc pumps & 14.5 cu. in. motors
• Performance
• Forward Speed: Up to 10 mph
• PTO Engagement: MagStop electromagnetic 200 ft-lb clutch with spot brake
• Fuel
• Capacity: 12-gallon single fuel tank
• Mower Deck
• Deck Size: 60 in.
• Series: UltraCut Series 4
• Construction: 10-gauge formed and continuously seam-welded top
• Lift: Foot-controlled
• Blades: 3 blades
• Blade Tip Speed: ~18,500 fpm
• Cutting Height Range: 1.0" to 5.5" (adjustable in 0.25" increments)
• Chassis & Tires
• Caster Tires: 13 x 6.5-6, smooth tread, semi-pneumatic
• Drive Tires: 24 x 12-12
• Steering Control: Hydraulically dampened twin levers
• Parking Brake: Lever-actuated disc brake
• Operator Station
• Seat: Deluxe adjustable suspension seat with 3" travel
• Standard Features:
• Engine hour meter
• Cup holder
• Electrical System
• Battery: 12-volt
• Alternator: 15-amp
• Dimensions & Weight
• Width: 72.8 in.
• Length: 83.1 in.
• Height: 70.5 in.
• Weight: 1,209 lbs.
• Warranty
• Consumer & Commercial Use: 5-Year / 1,250 Hours (No hour limit for first 2 years)

Width	Weight	Height	Length
0 Inch	1209 Pounds	0 Inch	0 Inch
